AECOM's Fast-Track Repair Saves Major Bridge

AECOM employees on site at I-495. From left to right: Nick Hetrick, PE, resident engineer; Harry Roecker, PE, vice president; John Milius, PE, associate vice president and Keystone district structures department manager; and Neil Shemo, PE, associate vice president and senior project manager.
tweet me:
Check out @AECOM's fast-track #solution to repair the @DelDOT's dual bridges of I-495. #Excellence #Safety
Monday, November 24, 2014 - 3:05pm

CAMPAIGN: Safety for Life

CONTENT: Article

The Delaware Department of Transportation (DelDOT) in the United States closed the dual bridges of I-495 and diverted 90,000 vehicles due to tilted piers supporting the northbound and southbound lanes.  On the same day, DelDOT called AECOM and, within an hour, AECOM geotechnical and structural engineers were at the site to design a fast-track repair solution.

Piers supporting the northbound and southbound lanes of I-495 over the Christina River were tilted, almost 2 feet out of plumb over the 60-foot column height.  55,000 tons of dirt stockpiled near the bridge had inadvertently overloaded the weak underlying soil layer and forced the piers and superstructure out of alignment.

On June 2, 2014, DelDOT closed the dual bridges to traffic and diverted 90,000 vehicles onto local streets.  The same day DelDOT called AECOM and, within an hour, AECOM geotechnical and structural engineers were at the site.  In the days that followed, they designed a fast-track repair solution that included 32 new drilled shaft foundations bearing on competent bedrock; underpinned some piers and replaced others; installed 16 shoring towers to temporarily support and then re-align the distorted superstructure; and then transferred the load from the temporary supports onto the new or repaired concrete piers.  It was an extremely complex project.

A successful team effort led to the safe reopening of the southbound bridge on July 31, five weeks ahead of schedule.  The more heavily deformed northbound structure followed on August 23, 11 days ahead of an already accelerated schedule.  Installation of the new foundations and jacking the superstructures into place from the temporary shoring towers required weeks of around-the-clock design and construction.

"We completed the critical task of realigning the northbound superstructure and reopening its lanes to traffic, 11 days ahead of schedule," said AECOM's Project Manager Neil Shemo.

"Every day counted to the travelling public and the community," added Harry Roecker, AECOM's technical lead.  "Our engineering and construction team solved one difficult challenge after another to reopen both of these bridges safely and way ahead of schedule."

AECOM's construction management team, led by Resident Engineer Nick Hetrick, helped coordinate the delivery of equipment and materials from around the nation to construct the new foundations.  Installation of the 4-foot diameter, 150-foot deep reinforced concrete drilled shafts in the low clearance beneath the existing superstructure was an extremely challenging endeavor which was executed flawlessly by the contractor with AECOM's oversight.

"The AECOM team of designers was like an extension of our staff," said Barry A. Benton, P.E, assistant director, bridge, DelDOT Transportation Solutions.  "Their innovative concepts and diligent work allowed for a very quick re-opening of this vital interstate."
